WLTP

Passenger vehicles (M type and Category N1 (i)):

• From 1^st September 2017, all new model introductions were subject to WLTP type approval and Real Driving Emissions (RDE) testing.
• From 1^st September 2018, all new sales received type approval under WLTP.
• From 1^st September 2019, all new registrations were be subject to RDE testing.

Light Commercial Vehicles (Categories N1 (ii), N1 (iii) and N2):

• From 1^st September 2018, all new Light Commercial vehicle model introductions were subject to WLTP type approval and Real Driving Emissions (RDE) testing
• From 1^st September 2019, all new sales of Light Commercial Vehicles received type approval under WLTP and all new registrations were subject to RDE testing.

WLTP values are now available to our customers.  NEDC CO₂ values derived from the WLTP test were used for taxation for the tax years 2017/2018; 2018/2019 and 2019/2020. It is only for new passenger vehicles registered after 1^st April 2020 (6^th April for BIK), that the WLTP values will be used for taxation purposes.

WLTP introduces much more realistic testing conditions. These include:

• More realistic driving behaviour;
• A greater range of driving situations; low, medium, high, extra high and combined;
• Longer test distances;
• More realistic ambient temperatures, closer to the European average;
• Higher average and maximum speeds;
• Higher average and maximum drive power;
• More dynamic and representative accelerations and decelerations;
• Shorter stops;
• Optional equipment: CO₂ values and fuel/energy consumption are provided for individual vehicles as built;
• Stricter car set-up and measurement conditions;
• Enables best and worst-case values on consumer information, reflecting the options available for similar car models.

Because of all these improvements, WLTP aims to provide a much more accurate basis for calculating a vehicle’s fuel/energy consumption and emissions.
This will ensure that lab measurements better reflect the on-road performance of a car.  Only compare fuel/energy consumption and CO₂ figures with other vehicles tested to the same technical procedures. These figures may not reflect real life driving results, which will depend upon a number of factors including the accessories fitted (post-registration), variations in weather, driving styles and vehicle load.

The standardised NEDC applied for all passenger vehicles and light commercial vehicles. It was introduced by the European Union in 1992 in order to provide comparable values for fuel/energy consumption.

Under RDE, a vehicle is driven over a wide range of real world driving conditions. Specific equipment installed on the vehicle collects data to verify that legislative caps for pollutants such as NOx are not exceeded.
Conditions include:

• Low and high altitudes
• Year-round temperatures
• Additional vehicle payload
• Up- and down-hill driving
• Urban roads (low speed)

To measure pollutant emissions as the vehicle is being driven on the roads, vehicles are fitted with Portable Emission Measuring Systems (PEMS) that provide a complete real-time monitoring of the key pollutants emitted by the vehicle (i.e NOx).



The PEMS used for regulated emissions are complex pieces of equipment that integrate advanced gas analysers, exhaust mass flow meters, weather station, Global Positioning System (GPS) and a connection to the vehicle networks.



There is no ‘standard’ PEMS equipment and equipment manufactured by different suppliers will always deliver slightly different results. The collected data is analysed to check that the RDE trip boundary conditions were achieved and that the emissions were within acceptable levels.

RDE step 1 (with a NOx conformity factor of 2.1) has applied since 1 September 2017 for new car types. It applies to all types as from September 2019.


RDE step 2 (with a NOx conformity factor of 1.0 plus an error margin of 0.5) applied from January 2020 for new types and then from January 2021 for all types.

A conformity factor is defined as a ‘not to exceed limit’ that takes into account a margin for error, which is present simply because the PEMS equipment does not deliver exactly the same results for each test. For example, PEMS are not as accurate as a full laboratory system so they will not measure to the same level of repeatable accuracy as a lab test. In practice, car manufacturers must set their design objectives well below the legal limit to be certain of complying.



What is the link between the CO₂ emissions and fuel/energy consumption of my car?



The amount of CO₂ a car emits is directly related to the amount of fuel/energy it consumes. For instance, a diesel car emitting 95g CO₂ per kilometre consumes around 3.7 litres of fuel per 100km, while a petrol car consumes around 4 litres/ 100km for the same CO₂ emissions.


Fuel/energy efficiency, sometimes referred to as fuel/energy economy, is the relationship between the distance travelled and the fuel/energy consumed.

The CO₂ emissions figure is used to determine the cost of Vehicle Excise Duty (‘car tax’) for new passenger vehicles during their first year of registration, in addition to any Company Car Tax. For those passenger vehicles approved under WLTP, a figure equivalent to what would have been achieved had the car been tested under NEDC has been used for taxation purposes – this is known as the NEDC equivalent value. From the 1st April (6^th April for BIK) 2020, the CO₂ value obtained under WLTP will be used instead of the NEDC equivalent. When WLTP does start to be used to calculate vehicle tax, it will only affect passenger vehicles that at that time are unregistered, i.e. the CO₂ figure that is used for tax purposes when the car is first registered will not change during its lifetime.

The new WLTP testing regime is still a laboratory-based standardised test but it seeks to provide more realistic testing conditions and a more accurate basis for assessing a vehicle model's fuel/energy consumption and emissions figures. In essence, the aim is to ensure that test conditions better reflect real world driving.

No. At present no changes to the model portfolio are planned, however certain engine and gearbox combinations will change. Individual models and their engines may have to be further engineered in order to achieve even higher efficiency and reduce NoX as per the regulations. However, models will not be discontinued as a result of WLTP.

Yes, there are. The driving cycles for exhaust and consumption measurement developed in Japan (JC 08) and the USA (FTP 75) are more closely oriented on specific situations on the country’s roads. For example, Japan’s driving cycle includes numerous stop-and-go phases and is carried out twice, once as a cold start and once as a warm start.

Yes, electric vehicles are also tested according to the new WLTP rules.

From 1^st January 2019, energy efficiency labels displayed alongside vehicles in showrooms, show a range of WLTP values for fuel/energy consumption (low, medium, high, extra high and combined) and a combined NEDC equivalent value (derived from the WLTP test) for CO₂.
